2014 Aluminum Wire Specifications
Diameter: 0.5mm-15mm
Length: Roll
Alloy Temper: HO,H12,H14,H16,H18,H19,H22,H24,H26,H28,F,H112,T651,T3,T451, T4,T6, ect.
Craft: Cutting, hemming, arc bending, welding, grinding, spraying, forming
Surface: Mill finish, no stains, without rough selvage, Anodizing
Certificate: ISO9001, CE, SGS, etc
Delivery Time: 7-20 days.
2014 Aluminum Wire Data Sheet
Equivalent Specifications of Aluminium 2014 Wire
Here is the table displaying the equivalent specifications of Aluminium 2014 wire:
| Standard Organization | Specification/Standard | Description |
|---|---|---|
| ASTM | ASTM B211 | Standard Specification for Aluminum and Aluminum-Alloy Rolled or Cold Finished Bar, Rod, and Wire |
| AMS | AMS 4115 | Aluminum Alloy, Rolled or Cold Finished Bars, Rods, and Wire |
| AMS | AMS 4029 | Aluminum Alloy Sheet and Plate |
| UNS | UNS A92014 | Unified Numbering System designation for 2014 alloy |
| ISO | ISO 6361 | Wrought aluminum and aluminum alloys – Sheets, strips, and plates |
| ISO | ISO 209-1 | Wrought aluminum and aluminum alloys – Chemical composition and forms of products – Part 1: Chemical composition |
| BS | BS EN 573-3 | Aluminum and aluminum alloys – Chemical composition and form of wrought products – Part 3: Chemical composition and form of products |
| BS | BS EN 755-2 | Aluminum and aluminum alloys. Extruded rod/bar, tube, and profiles. Mechanical properties |
| DIN | DIN 3.1255 | Aluminum alloy, technical specifications for wrought products |
| AA | AA 2014 | Aluminum Association designation |
| Europe | AlCu4SiMg | European equivalent designation |
This table shows the various standards and specifications equivalent to Aluminum 2014 wires. If you want to know more news, you can contact us directly!
Chemical Composition of 2014 Aluminum Wires
| Element | Al | Cu | Mg | Mn | Si | Fe | Zn | Ti | Others |
|---|---|---|---|---|---|---|---|---|---|
| Percentage (%) | 90.7 – 94.7 | 3.9 – 5.0 | 0.2 – 0.8 | 0.4 – 1.2 | 0.5 – 1.2 | 0.7 max | 0.25 max | 0.15 max | 0.15 max each, 0.05 max total |
There are some differences in the chemical composition of aluminum products from different aluminum manufacturers, but they are all within a certain range. If you want to know more, please contact us directly!
Mechanical Properties of 2014 Aluminium Wires
| Property | T3 | T4 | T6 | T651 |
|---|---|---|---|---|
| Tensile Strength (MPa) | 380 – 460 | 400 – 480 | 450 – 505 | 470 – 530 |
| Yield Strength (MPa) | 240 – 320 | 250 – 350 | 385 – 450 | 410 – 470 |
| Elongation (% in 50mm) | 10 – 15 | 12 – 18 | 10 – 12 | 9 – 11 |
| Hardness (HB) | 105 – 120 | 110 – 125 | 120 – 140 | 125 – 145 |
Notes:
- T3: Solution heat-treated and then cold worked.
- T4: Solution heat-treated and naturally aged to a substantially stable condition.
- T6: Solution heat-treated and then artificially aged.
- T651: Solution heat-treated, stress-relieved by stretching, and then artificially aged.
Physical Properties of 2014 Aluminum Wires
| Property | Value |
|---|---|
| Density | 2.80 g/cm³ |
| Melting Point | 510 – 638 °C (950 – 1180 °F) |
| Thermal Conductivity | 160 W/m·K |
| Electrical Conductivity | 36% IACS (International Annealed Copper Standard) |
| Coefficient of Thermal Expansion | 23.2 µm/m·K (20-100°C) |
| Modulus of Elasticity | 73.1 GPa |
| Poisson’s Ratio | 0.33 |
Tempers of 2014 Aluminum Wires
O Temper (Annealed): The material is fully annealed for maximum ductility and lowest strength, making it ideal for forming and bending.
T3 Temper: After solution heat treatment, the material is cold-worked, offering a balance of moderate strength and good ductility.
T4 Temper: The material undergoes solution heat treatment and natural aging, resulting in higher strength while maintaining good ductility.
T6 Temper: The material is solution heat-treated and artificially aged, providing high strength with reduced ductility, suitable for high-stress applications.
T651 Temper: Similar to T6 but includes stress relief by stretching, offering high strength and good dimensional stability.
T6511 Temper: Includes additional straightening compared to T651, ensuring straightness for precision applications.
H Temper (Strain-hardened): Achieves increased strength through cold working but is less common for 2014 aluminum, as this alloy is mainly heat-treatable.
For more information or pricing on 2014 aluminum coils, please get in touch with HXM and our team will respond to your message within 24 hours!
Applications of 2014 Aluminum Wire Metal
2014 Aluminum Wire Packages
The following is our company’s standard aluminum wire export packaging. If the customer has any packaging requirements, our company can meet them.
FAQ
What Is 2014 Aluminum Wire?
2014 Aluminum Wire is a high-strength aluminum alloy consisting primarily of aluminum and significant amounts of copper, as well as smaller amounts of other elements such as manganese, magnesium, silicon, and iron. It is known for its high strength, excellent machinability, and good wear resistance. These properties make it particularly suitable for the aerospace, military, and automotive industries where high performance and reliability are critical.
Comparison Between 2014 Aluminum Wire and 2011 Aluminum Wire
2014 Aluminum Wire: Offers higher strength and is suitable for high-stress applications in aerospace, military, and automotive industries. It has excellent machinability and is heat treatable, but it has lower corrosion resistance.
2011 Aluminum Wire: Known for its exceptional machinability due to the presence of lead and bismuth. It is ideal for precision machining applications, especially in high-volume production environments. It also
How Can I Get A Sample Of 2014 Aluminum Wires?
Yes, we can provide small pieces of samples for free.
Processing and Processing
2014 aluminum wire can be processed and treated in several ways:
Heat Treatment: Its mechanical properties can be significantly improved by heat treatment.
Machining: Due to its good cutting properties, complex mechanical processing can be carried out.
Welding: Although the welding performance of 2014 aluminum wire is not as good as some other aluminum alloys, it can also be connected by appropriate welding methods when necessary.
Features of 2014 Aluminum Wire
High Strength: 2014 aluminum wire has very high strength and is suitable for use in applications that require high-strength materials.
Good Machinability: This can be strengthened by heat treatment and has good cutting performance.
Corrosion Resistance: Although the corrosion resistance of 2014 aluminum alloy is slightly lower than some other aluminum alloys, its corrosion resistance can be improved through appropriate surface treatment.
Good Fatigue Performance: Shows good fatigue performance under repeated stress.
Why Choose Us As Your 2014 Aluminum Wire Supplier?
Choosing the right 2014 aluminum wire supplier is crucial to ensure the quality and reliability of the material. Here are the compelling reasons why you should choose us as your 2014 aluminum wire supplier:
High-Quality Products
Strict quality control: We adhere to strict quality control measures to ensure that our 2014 aluminum wire meets industry standards and specifications.
Certified materials: Our products are certified to meet ASTM, AMS, ISO, and other relevant standards.
Extensive Experience
Industry expertise: With years of experience in supplying aluminum products, we have the expertise to understand and meet your specific needs.
Technical knowledge: Our team has deep technical knowledge of 2014 aluminum wire, including its properties, applications, and processing methods.
Customized Options
Tailored solutions: We provide customized solutions to meet your unique requirements, including specific tempering conditions, sizes, and lengths.
Value-added services: We provide additional services such as cutting, machining, and heat treatment to provide you with ready-to-use products.
Competitive Pricing
Cost-effective: We offer competitive pricing without compromising on quality, ensuring you get the best value for your investment.
Advanced Technology
State-of-the-art facilities: Our production facilities are equipped with the latest technology to produce high-quality 2014 aluminum wire.
Innovation: Continuous investment in research and development to innovate and improve our products and services.
Comprehensive Inventory
Wide range: We have a wide range of 2014 aluminum wire in stock in various sizes, hardnesses, and specifications to meet the needs of different customers.
Availability: Off-the-shelf supply ensures timely delivery and reduces project downtime.
Choosing us as your 2014 aluminum wire supplier means working with a reliable, experienced, customer-centric company dedicated to meeting your specific needs. Our commitment to quality, competitive pricing, and excellent service makes us the best choice for your 2014 aluminum wire needs.
