3005 Aluminum Pipe is part of the 3000 series of aluminum alloys, with manganese as the main alloying element. It has moderate strength, excellent corrosion resistance, and good machinability, making it a preferred material for a wide range of applications in many industries such as construction, automotive, HVAC systems, etc.
Looking for a reliable 3005 Aluminum Tube supplier? We provide high-quality 3005 Aluminum Pipe with competitive prices and stable inventory to meet the diverse needs of global customers.
3005 Aluminum Pipe & Tube Specifications
Standards: ASTM, ASME, AMS, GB/T, JIS
Thickness: 0.2-500mm, etc.
Width: 20-2650mm, etc.
Length: Customized
Shape: Round, Square, Rectangular, etc.
Material Temper: F, O, T4, T6, T651, H14, H112
Delivery Time: 7-20 days.
3005 Aluminum Tube & Pipe Data Sheet
Equivalent Of Aluminum 3005 Tube
| Country/Region | Standards Organization | Standard | Description |
|---|---|---|---|
| USA | ASTM | ASTM B209 | Standard Specification for Aluminum and Aluminum-Alloy Sheet and Plate |
| Europe | EN | EN 485-2 | Aluminum and Aluminum Alloys – Sheet, Strip and Plate – Mechanical Properties |
| Japan | JIS | JIS H4000 | Aluminum and Aluminum Alloy Sheets and Plates |
| China | GB | GB/T 3880 | Aluminum and Aluminum Alloy Plates, Sheets, and Strips |
| Germany | DIN | DIN 1725 | Aluminum and Aluminum Alloys – Sheets and Plates |
| International | ISO | ISO 6361-2 | Wrought Aluminum and Aluminum Alloy Sheets, Strips, and Plates – Mechanical Properties |
Chemical Composition of 3005 Aluminum Tube
Mechanical Properties and Tempers of 3005 Aluminium Tube
| Temper | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (Brinell) |
|---|---|---|---|---|
| H12 | 130 – 170 | 90 – 110 | 12 – 14 | ~45 HB |
| H14 | 140 – 185 | 100 – 125 | 10 – 12 | ~46 HB |
| H16 | 150 – 195 | 110 – 135 | 8 – 10 | ~47 HB |
| H18 | 160 – 205 | 120 – 145 | 8 – 9 | ~48 HB |
| H22 | 130 – 175 | 95 – 115 | 12 – 14 | ~45 HB |
| H24 | 140 – 185 | 105 – 130 | 10 – 12 | ~46 HB |
| H26 | 150 – 195 | 115 – 140 | 8 – 10 | ~47 HB |
| H28 | 160 – 205 | 125 – 150 | 8 – 9 | ~48 HB |
| H32 | 130 – 170 | 90 – 115 | 12 – 14 | ~45 HB |
| H34 | 140 – 185 | 100 – 125 | 10 – 12 | ~46 HB |
| H36 | 150 – 195 | 110 – 135 | 8 – 10 | ~47 HB |
| H38 | 160 – 205 | 120 – 145 | 8 – 9 | ~48 HB |
For high-quality 3005 aluminum tube and professional assistance, contact HXM, your reliable supplier of aluminum products.
Different Tempers of 3005 Aluminum Tubes
-
Strain-Hardened (H12, H14, H16, H18): These tempers involve increasing hardness through cold working. The numbers indicate the degree of strain hardening, with H18 being the hardest.
-
Strain-Hardened and Partially Annealed (H22, H24, H26, H28): These tempers involve a combination of strain hardening and partial annealing to improve formability while retaining some hardness.
-
Strain-Hardened and Stabilized (H32, H34, H36, H38): These tempers provide stability in mechanical properties, combining strain hardening with stabilization treatments to enhance strength and durability.
Applications of 3005 Aluminum Pipe Metal
Building and Construction: Used in curtain walls, roofs, guardrails, and architectural decoration.
Automotive Industry: Suitable for lightweight car bodies and components to improve fuel efficiency.
HVAC Systems: Widely used in heat exchangers and air guides in HVAC.
Marine Engineering: Used for corrosion-resistant hull and deck structures.
3005 Aluminum Pipe & Tube Packages
The following is our company’s standard aluminum pipe & tube export packaging. If the customer has any packaging requirements, our company can meet them.
