2011 Aluminium Sheets Specifications
Thickness: 0.2-200mm, etc.
Width: 500-3100mm, etc.
Length: Customized
Material Temper: O, H14, H18, etc.
Delivery Time: 7-20 days.
Standards: ASTM B209 / ASME SB209/DIN 1725/JIS H4000
Description of 2011 Aluminum Sheet & Plate
2011 Aluminum is a high-strength alloy with excellent machinability and surface finish. It is known for its ability to produce high-quality surfaces and intricate details, making it ideal for precision machining applications. This alloy belongs to the 2000 series aluminum alloys, which offer high strength and good machinability.
At HXM, we are committed to providing high-quality 2011 aluminum products that meet your specific needs. For detailed product information and pricing, please contact us today.
2011 Aluminum Sheets & Plates Data Sheet
Equivalent Specifications of Aluminium 2011 Sheet & Plate
here’s a table displaying the equivalent specifications of the Aluminum 2011 Plate:
| Specification | Standard/Organization | Details |
|---|---|---|
| EN | EN AW-2011 | European Norm equivalent for 2011 aluminum alloy |
| ASTM | ASTM B209 | Standard Specification for Aluminum and Aluminum-Alloy Sheet and Plate |
| UNS | UNS A92011 | Unified Numbering System designation for 2011 aluminum |
| AA | AA2011 | Aluminum Association designation for 2011 alloy |
| ISO | ISO 6361 | International Organization for Standardization – Wrought aluminum and aluminum alloy sheets, strips, and plates |
| DIN | DIN 3.1655 | Deutsches Institut für Normung (German Institute for Standardization) equivalent for 2011 aluminum |
| JIS | JIS H 4000 | Japanese Industrial Standards for aluminum and aluminum alloys |
| GB | GB/T 3190 | National Standard of the People’s Republic of China for aluminum and aluminum alloy chemical composition |
| AMS | AMS 4027 | Aerospace Material Specification for 2011 aluminum alloy sheets and plates |
| SAE | SAE J454 | Society of Automotive Engineers – Wrought aluminum and aluminum alloy sheets and plates |
This table outlines the various standards and specifications that are equivalent to Aluminum 2011. If you would like more information, please contact us directly!
Chemical Composition of 2011 Aluminum Plates
Here is the chemical composition of the 2011 Aluminum Plates:
| Element | Composition (%) |
|---|---|
| Al | Balance |
| Cu | 5.0 – 6.0 |
| Fe | ≤ 0.7 |
| Si | ≤ 0.4 |
| Zn | ≤ 0.3 |
| Pb | 0.2 – 0.6 |
| Bi | 0.2 – 0.6 |
| Others | Each ≤ 0.05%, Total ≤ 0.15 |
This is the specific percentage range of various elements of the 2011 aluminum plate, which ensures its unique properties and performance characteristics. If you want to know more, please contact us directly!
Mechanical Properties of 2011 Aluminium Sheets
| Property | Value |
|---|---|
| Ultimate Tensile Strength | 310 MPa (45 ksi) |
| Yield Strength | 276 MPa (40 ksi) |
| Elongation | Approximately 10% in 2 inches |
| Hardness | 95 HB |
| Modulus of Elasticity | 69 GPa (10,000 ksi) |
| Shear Strength | 207 MPa (30 ksi) |
The mechanical properties demonstrated above make the 2011 aluminum sheet an excellent choice for applications that require high strength and precision machining. Its excellent machinability and ability to achieve a high-quality surface finish ensure its optimal performance in a variety of industrial uses.
For more information on the 2011 aluminum sheet or to request a quote, please contact HXM. Our sales team will respond to you within 24 hours!
Physical Properties of 2011 Aluminum Plates
| Property | Value |
|---|---|
| Density | 2.85 g/cm³ (0.103 lb/in³) |
| Melting Point | 502 – 638°C (936 – 1180°F) |
| Thermal Conductivity | 121 W/m·K |
| Electrical Conductivity | 32% IACS |
| Coefficient of Thermal Expansion | 23.6 x 10⁻⁶ /°C (13.1 x 10⁻⁶ /°F) |
| Specific Heat Capacity | 0.87 J/g-°C |
These physical properties highlight the excellent thermal and electrical conductivity of the 2011 aluminum plate, as well as its suitability for high-temperature applications due to its melting point range and thermal expansion coefficient. Specific heat capacity and density further highlight the efficiency and reliability of this material.
For more details on 2011 aluminum sheet or 2011 aluminum plate prices, please contact HXM, our team will respond to you within 24 hours!
Tempers of 2011 Aluminum Plates
| Temper Designation | Description | Typical Applications |
|---|---|---|
| 2011-T3 | Solution heat-treated, cold-worked, and naturally aged. | Suitable for applications requiring high strength and good machinability. |
| 2011-T4 | Solution heat-treated and naturally aged. | General-purpose applications with a good balance of strength and ductility. |
| 2011-T6 | Solution heat-treated and artificially aged. | Offers the highest strength and is used in critical components where high performance is required. |
| 2011-T8 | Solution heat-treated, cold-worked, and artificially aged. | Provides excellent machinability and good strength, often used in complex, precision machined parts. |
| 2011-O | Annealed (softened). | Ideal for applications requiring maximum ductility and formability. |
These tempering treatments allow 2011 aluminum sheets to be customized to specific application requirements, ensuring optimal performance in a variety of industrial and engineering environments.
For more information or pricing on 2011 aluminum sheets, please contact HXM and our team will respond to your message within 24 hours!
2011 Aluminum Sheet & Plate Application
2011 Aluminum Sheet & Plate is widely used across various industries due to its excellent machinability, high strength, and good surface finish. Here are some of its common applications:
1. Precision Machined Components
- Ideal for producing intricate and complex parts with tight tolerances.
- Used in the manufacturing of jigs, fixtures, and other precision tooling components.
2. Automotive Industry
- Used for making components like valves, fasteners, and connectors due to its high strength and excellent machinability.
- Common in parts requiring high precision and reliability.
3. Aerospace Industry
- Utilized in the production of aerospace components where high strength and lightweight properties are critical.
- Suitable for making aircraft fittings and other structural components.
4. Electrical Connectors
- Its good electrical conductivity makes it suitable for electrical connectors and components.
- Used in various electrical and electronic applications requiring reliable conductivity.
5. Fasteners and Hardware
- Commonly used for producing screws, nuts, and bolts.
- Provides high strength and durability, essential for hardware applications.
6. Valve Parts and Couplings
- Ideal for manufacturing valve bodies and couplings due to its excellent machinability.
- Ensures a good surface finish, which is crucial for sealing and fluid control applications.
7. General Engineering Applications
- Employed in a wide range of engineering applications where machinability and strength are important.
- Used for making various machine parts and components.
8. Instrumentation and Measuring Devices
- Suitable for parts in measuring instruments and devices requiring high precision and accuracy.
- Ensures consistent performance and reliability in critical applications.
The versatility of the 2011 aluminum sheet makes it the material of choice for many industries, combining strength, processability, and surface finish to meet a variety of application needs.
For more information or prices on the 2011 aluminum sheet, please contact HXM and our team will respond to your message within 24 hours!
