1050 Aluminum Bars

1050 Aluminum Bars Specifications

Standards: ASTM, ASME, AMS, GB/T, JIS

Aluminum bar form: Aluminum round, hexagonal, flat, semi-circular, oval, rectangular black, and glossy finish

Aluminum round bar diameter: 0.1-600mm, etc.

Aluminum hexagonal bar: 0.1-600mm, etc.

Aluminum angle bar size: 0.5mm*40mm*40mm-20mm*400mm*400mm

Aluminum flat steel thickness: 0.1-600mm, etc.

Aluminum flat bar size: 1-2500mm, etc.

Aluminum round bar length: 1-12m, random, fixed, and cut length or according to customer requirements

What is 1050 Aluminum Bars?

1050 Aluminum Bars are an aluminum product made from the 1050 aluminum alloy. This alloy belongs to the 1000 series, characterized by high purity and excellent corrosion resistance. The 1050 alloy contains a minimum of 99.5% aluminum, making it one of the purest forms of aluminum available. This high purity level imparts specific properties that make 1050 Aluminum Bars suitable for various applications.

High Purity: Contains 99.5% minimum aluminum, ensuring high purity.
Excellent Corrosion Resistance: Performs well in both atmospheric and aqueous environments.
Good Electrical Conductivity: High electrical conductivity makes it ideal for electrical applications.
High Thermal Conductivity: Efficient at dissipating heat, making it suitable for heat exchangers and similar applications.
Good Formability: Easily shaped and formed, making it suitable for various fabrication processes.
Non-Toxic: Safe for use in food processing and handling applications.

1050 Aluminum Bars Data Sheet

Aluminium 1050 Bar Equivalent Grades:

Here are the equivalent grades of Aluminium 1050 Bar across various standards and organizations:

Standard	Equivalent Grade
EN	EN AW-1050
ASTM	ASTM B491, ASTM B491M
UNS	UNS A91050
AA	AA1050
ISO	ISO 209-1: 1050A
DIN	DIN 3.0255
JIS	JIS H 4000: 1050
GB	GB/T 3190: 1050

We provide high-quality aluminum bar products that meet these international standards. Our products ensure reliability and compatibility across various applications and markets. Contact us today to learn more or request a 1060 aluminum bar price.

Chemical Composition Of 1050 Aluminum Bars:

Element	Al	Fe	Si	Cu	Mn	Mg	Zn	Other Elements	Total
Composition (%)	99.5% min	0.40% max	0.25% max	0.05% max	0.05% max	0.05% max	0.05% max	0.03% max	0.10% max

For detailed specifications or to place an order, please contact us directly and we will reply to you within 24 hours – your trusted 1050 Aluminum Bar Supplier.

Mechanical Properties Of 1050 Aluminium Alloy Bars:

Property	Annealed (O)	H14 Temper	H18 Temper
Tensile Strength	70-100 MPa (10-15 ksi)	105-145 MPa (15-21 ksi)	125-165 MPa (18-24 ksi)
Yield Strength	30-50 MPa (4-7 ksi)	85-120 MPa (12-17 ksi)	110-145 MPa (16-21 ksi)
Elongation	20-30%	3-8%	1-3%
Hardness (Brinell)	25 HB	35-47 HB	40-55 HB

The data given by different aluminum metal manufacturers may have differences. If you want to determine whether our company’s 1050 aluminum bar is suitable for your project, we can provide free samples for you to test.

1050 Aluminum Bars Application

1060 Aluminum Bars, known for their high purity and excellent properties, are widely used in various industries. As a member of the 1000 series aluminum alloys, 1060 aluminum bars contain more than 99.6% aluminum, making them an ideal choice for applications requiring superior corrosion resistance, high electrical and thermal conductivity, and excellent formability. Here are some of the common applications of 1060 Aluminum Bars:

1. Electrical Industry

Electrical Conductors: Due to their high electrical conductivity, 1060 aluminium bars are used in the manufacturing of electrical conductors and bus bars.
Transformer Components: Ideal for transformer windings and other components requiring high purity and excellent conductivity.

2. Chemical and Food Processing Industry

Chemical Equipment: Employed in the construction of chemical processing equipment such as storage tanks, reactors, and piping, thanks to their excellent corrosion resistance.
Food Processing Equipment: Suitable for making food processing equipment and containers, ensuring safety and hygiene due to their non-toxic properties.

3. Heat Exchangers

Heat Sinks: Used in the manufacturing of heat sinks and other heat exchange components because of their high thermal conductivity.
Cooling Systems: Utilized in cooling systems and radiators, providing efficient heat dissipation.

4. Architectural Applications

Building Structures: Employed in building facades, cladding, and structural components for their good formability and aesthetic appeal.
Interior Design Elements: Suitable for decorative panels, ceiling tiles, and other interior design applications.

5. Automotive Industry

Engine Components: Used for manufacturing various engine components, including heat shields, due to their high thermal conductivity and resistance to corrosion.
Automotive Trim and Fittings: Suitable for producing automotive trim and fittings because of their formability and surface finish.

The versatility and performance of the 1060 aluminium bar make it the material of choice in many applications that require high purity, corrosion resistance, and excellent conductivity.

The above are some of the applications of the 1060 aluminum bar we show. If you are looking for a 1060 aluminum bar supplier for your project, we can provide you with 1060 aluminum bar samples for you to test whether it is suitable for your project.
